Answers about Sonar Technologyby Brad Wiegmann
(Editor’s Note: Please welcome writer, photographer and crappie fishing expert extraordinaire, Brad Wiegmann, to the elite stable of CrappieNOW Magazine contributors. Every month Wiegmann will be providing the absolute latest and greatest information on the ever-changing world of fishing electronics.)
Editor’s Note: When shopping for new depth finders, novices – and even advanced anglers – are usually extremely confused by the wide array of choices and the accompanying technical jargon. In this month’s column on electronics, CrappieNOW expert columnist Brad Wiegmann explains some of the technology and jargon to help you better understand which unit might be best for you.
Sonar technology consists of traditional 2D sonar, CHIRP traditional sonar, scanning sonar, 3D sonar and phased array scanning sonar. Each one has advantages and disadvantages, but they are all commonly used by anglers to navigate and identify objects, wood, rock, bottom composition and fish. Today’s angler is often utilizing multiple Multifunction Devices (MFD) to see several sonar technologies.
Notice that all of the transducers use a unit of measurement referred to as frequency. Frequency is the number of cycles per second. So, one kilohertz would be equal to 1,000 Hertz or 1,000 cycles per second. A 50kHz has a wide sound wave covering a larger area while the 200kHz a short, tight sound wave pulse covering a smaller area. What degree cone angle will also influence the MFD imaging.
Traditional 2D sonar operates in lower frequencies from 50-, 83-to 200-kHz. Use the lower to see more with less definition and higher 200kHz for a smaller area, but better definition.
CHIRP – which stands for Compressed High Intensity Radar Pulse – Traditional 2D Sonar produces a continuous sweep of set frequencies from the transducer and waits for the sound wave pulse to reflect back from objects, wood, rock or fish to produce images. MFD with the correct transducer may have medium and high CHIRP frequencies. A lower frequency medium CHIRP covers a large area compared to the sharper imaging, narrow high CHIRP.
Down- or side-scanning sonar MFDs have a large rectangular transducer that produces super thin, high ultra-frequency beam. The lower 455kHz frequency allows and angler to see more, but with less definition than 800kHz or now the popular 1.2MHz frequency. Although the higher 1.2MHz produces super sharp images it causes the imaging to deteriorate in deep water. Side scan may reach out to 400 feet to the left and right of the boat. To produce images in down or side scan the boat must be moving forward unlike phased array scanning sonar.
Garmin (LiveScope), Lowrance (ActiveTarget) and Humminbird (MEGA Live) now produce MFDs that utilize phased array scanning sonar. Garmin LiveScope has the broadest frequency at 530- to 1,100kHz. Lowrance has the next largest at 550-to 1,100kHz. Humminbird only lists its frequency at 1,950-kHz.
Assuming from the frequency numbers Garmin will have the best imaging followed by Lowrance than Hummingbird. There is another factor and that’s the fact these transducers are steerable beams, but again are different sizes. Garmin has the widest beam at 20 degrees by 135 degrees while the Lowrance is 18 degrees by 135. Humminbird falls out of competition at 20 degrees by 120. What that means is Garmin is showing almost 2 feet more in imaging at a range of 50 feet. Note the wider 20-degree Garmin LiveScope beam allows anglers to see more at shorter distances, however, the Lowrance ActiveTarget better imaging at distances farther out.
3D sonar is normally not used in crappie fishing, but produces a three-dimensional view.
Obviously there have been books about sonar technology so it is impossible for us to share everything here. Hopefully, however, this will help you make better decisions on which unit is best for you.
